Integrated fixed deviceDimensions with packaging (H x W x D) [mm(in.)]Installation typeWeight with packaging [kg(lb)]Typical heat dissipation [BTU/hour]Maximum heat dissipation [BTU/hour]100% power consumption [W]MTTR [hour]Noise at normal temperature (acoustic power) [dB(A)]Noise at normal temperature (acoustic pressure) [dB(A)]Number of power slotsMaximum number of physical ports on the entire deviceMaximum number of 40GE portsMaximum number of 10GE portsMaximum number of 2.5GE portsMaximum number of FE portsRedundant power supplyRestriction on the operating temperature variation rate [°C(°F)]Long-term operating relative humidity [RH]Storage altitude [m(ft.)]Rated input voltage [V]Maximum input current [A]MemoryStorageEth Management portHardware real-time power detectionRTCComplete device sleepingPower supply surge protection [kV]Types of fansAirflow directionMaximum PoE power consumption [W]PoE++ power interfacesFull load PoE power consumption 30W (802.3at)Full load PoE++ power consumption 90W (802.3bt)

V600R022C10
	Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 160.0 mm (1.72 in. x 17.4 in. x 6.3 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 165.2 mm (1.72 in. x 17.4 in. x 6.5 in.)
	1
	1.6 (3.53)
	10.4
	10.55
	5.82
	67.79
	>0.99999
	Noise-free (no fans), < 30
	0
	0
	0
	0
	0
	10
	Not supported
	0°C to 40°C (32°F to 104°F) at an altitude of 0-1800 m (0-5906 ft.)
	–40°C to +70°C (–40°F to +158°F)
	0–5000 m (0–16404 ft.)
	AC built-in
	AC input: 90 V AC to 264 V AC; 45 Hz to 65 Hz
	Quad-core, 800 MHz
	NAND Flash: 512 MB
	Not supported
	Not supported
	Not supported
	Not supported
	Common mode: ±4 kV
	IP20
	Natural heat dissipation
	Not supported
	-
	-
	-
	EMC certification Safety certification Manufacturing certification
