SPECIFICATIONS

PRODUCT DIMENSION: 283*180*173 mm
NET WEIGHT   : 1.049kg
POWER CABLE LENGTH: 1m
HOUSING MATERIAL: ABS+PC
HOUSING: Black
HOSING FLAME RETARDANCE: UL94 V-0 750C FIRE-PROOF
INGRESS PROTECTION(IP): IP65
TUYA SDK VERSION: 4.9.16
IMAGE SENSOR: 1/2.9" 2Megapixel progressive CMOS
SENSOR BRAND AND MODEL: GALAXYCORE, GC2063
MAIN CHIPSET BRAND AND MODEL: GOKE, GK7202V300
4G MODULE BRAND AND MODEL: SIMCOM, A7670
LENS BRAND AND MODEL: Hongli, HL-1027
LENS LENGTH: 17.25mm
APERTURE: F2.2
SPEAKER: 8Ω1W
ANTENNA GAIN (DBI): 3dBi
POWER SUPPLY: DC 5V1.5A
WORKING POWER CONSUMPTION: Max 4.3W±10%
STANDBY POWER CONSUMPTION: 3mW
LIVE STREAM VIDEO RESOLUTION: FHD(1920*1080) / SD(640*360) @15fps
NOTIFICATION IMAGE RESOLUTION: SD(480*320)
LIVE STREAM EFFECTIVE PIXELS: 2MP
LIVE STREAM EFFECTIVE PIXELS: BY HW OR SW   Hardware straight out
ANGLE OF VIEW(H/V/D): 101° / 45° / 125°
ANGLE OF PAN AND TILT: 350° / 75°
MICROPHONE SENSITIVE: -38dB
NOISE REDUCTION: 3D DNR
AUDIO INPUT: Built in Mic
AUDIO OUTPUT: Built in Speaker
AUDIO COMPRESSION: PCM / AAC
VIDEO COMPRESSION: H.265 / H.264
FRAME RATE: Main Stream:1.5Mbps / Sub Stream: 512Kbps
IR CUT: Support
IR ON/OFF CONTROL: Auto
IR DISTANCE: 8-12m(23ft)
NIGHT VISION MODE: Infrared mode & Color mode
NUMBER OF INFRARED LIGHT: 4pcs
NUMBER OF WHITE LIGHT: 4 pcs
WHITE LIGHT COLOR TEMPERATURE: 6500K±350K
WHITE LIGHT COLOR RENDERING: INDEX   Ra>80
WHITE LIGHT LUMINOUS FLUX: 150lm
WHITE LIGHT LIGHTING ANGLE: 95°
WIRELESS STANDARD: LTE-FDD
WIRELESS FREQUENCY: B1/B3/B5/B7/B8/B20
WORKING TEMPERATURE: -10°C - +50°C
WORKING HUMIDITY: 10% - 95%RH(No condensation)
PAIRING METHOD: 4G Scan QR Code
TWO-WAY TALK: Support
MOTION DETECTION: Support
HUMANOID FILTERING: Support
CLOUD STORAGE: Support
SIREN: Support
CONDITION TO TRIGGER: LOCAL STORAGE: Motion detection & Preview
CONDITION TO TRIGGER: CLOUD STORAGE: Motion detection
STATUS INDICATOR LED COLOR: Blue, Red
PIR SET: Support
LOCAL STORAGE SD SLOT: Micro SD Slot (up to 128GB)
LOCAL SIM CARD SLOT: Nano SIM
VOICE SOLUTION CONFIGURATION: Amazon Alexa, Google Assistant
BATTERY TYPE: 21700 Lithium battery pack
BATTERY CAPACITY: 3.7V 9000mAh
BATTERY CHARGING TIME: (INPUT DC 5V1A): 10hours
BATTERY LIFE: 20 days (triggered 8 times per day)
SOLAR PANEL DIMENSION: 12*17.5 cm
SOLAR PANEL NET WEIGHT: 350g
SOLAR PANEL POWER CORD LENGTH: 2m
SOLAR PANEL SHELL MATERIAL: ABS+PC
SOLAR PANEL CRAFTSMANSHIP: PET
